Race Face AR Offset Rims
Out of stock
Our popular AR rims have been updated for 2019 with our asymmetric rim profile, improving spoke tension balance and overall wheel build quality and durability. The rim extrusion has also been improved to increase impact performance for more aggressive applications. With 5 widths available, tubeless compatible rim profile, and colour match capabilities, these rims are ready for any build you can throw at them.
R1,540.00 – R1,580.00
Compare- Sizes from 25mm internal width to 40mm
- Tubeless ready with strong tire retention bead
27.5″ TUBELESS READY
- WHEEL SIZE 27.5″
- RIM WEIGHT 25mm – 440g, 30mm – 504g, 35mm – 542g, 40mm – 585g
- FINISH BRUSHED BLACK ANODIZE / VINYL DECALS
- TYPE TUBELESS READY CLINCHER(tape and valve kit sold separately)
- RIM MATERIAL SLEEVED 6061 ALLOY
- RIM DEPTH 20mm
- RIM OFFSET 4.5mm
- INTERNAL RIM WIDTH 25mm, 27mm, 30mm, 35mm, 40mm
- EXTERNAL RIM WIDTH 29mm, 31mm, 34mm, 39mm, 44mm
- SPOKE HOLES 32
- RIM ERD 554
- MAX SPOKE TENSION 122KGF / 1200N
- 29″ TUBELESS READY
WHEEL SIZE 29″
- RIM WEIGHT 25mm – 485, 30mm – 535g, 35mm – 573g, 40mm – 616g
- FINISH BRUSHED BLACK ANODIZE / VINYL DECALS
- TYPE TUBELESS READY CLINCHER(tape and valve kit sold separately)
- RIM MATERIAL SLEEVED 6061 ALLOY
- RIM DEPTH 20mm
- RIM OFFSET 4.5mm
- INTERNAL RIM WIDTH 25mm, 27mm, 30mm, 35mm, 40mm
- EXTERNAL RIM WIDTH 29mm, 31mm, 34mm, 39mm, 44mm
- SPOKE HOLES 32
- RIM ERD 592
- MAX SPOKE TENSION 122KGF / 1200N
Please Note: We must insist you use nipple washers on all Race Face AR rims to complete the wheel build.
